Dongguan Baoyu Machinery Co., Ltd.

Company Introduce

Established in 2007, Dongguan Baoyu Machinery Co., Ltd. is a national high-tech enterprise integrating R & D, production, sales and service of high-end equipment. Baoyu CNC machine tools have a complete range of products, including five-axis linkage machining center machine, vertical and horizontal dual-purpose machining center machine, drilling and tapping machine, parts machining center, mold machining center, engraving and milling machine, CNC lathe, gantry machining center, gantry section machine, horizontal machining center machine and other series of precision machining equipment.

Five-axis machining center

1: Crown block structure, the worktable is fixed on the bed, and the sliding plate, cross beam and spindle box move to realize the feeding of X, Y and Z coordinate axes. 2. The whole machine adopts gantry movable beam structure, with good rigidity, uniform stress, good thermal balance and stable precision. 3. X, Y and Z axis guide rails adopt rolling linear guide rails, with small dynamic and static friction, high sensitivity, small vibration at high speed, no crawling at low speed, high positioning accuracy, excellent servo drive performance, and improved accuracy and accuracy stability of the machine tool. 4. The servo motors of X, Y and Z axes are directly connected to the high-precision ball screw through the diaphragm coupling, which reduces the intermediate links and realizes gapless transmission. The feed is flexible, the positioning is accurate and the transmission precision is high. The servo motor of Z axis has the function of automatic brake. In the case of power failure, the automatic brake can hold the motor shaft tightly so that it can not rotate, which plays a role in safety protection. 5. The spindle can be HSK electric spindle. The electric spindle is a built-in spindle with a built-in three-phase permanent magnet synchronous induction motor. It is controlled by a frequency converter for stepless speed change. The maximum speed is 30000 rpm. It has high rotation accuracy and good rigidity. The thermal elongation is less than 1 wire, which can ensure the machining accuracy of the spindle. 6. Umbrella-type servo tool magazine is adopted. The manipulator tool changing device is installed on the machine body. When changing tools, the cutter head is driven and positioned by the servo motor. After the spindle reaches the tool changing position, the tool changing device completes the tool returning and feeding. The tool changing process is fast and accurate. 7: The machine tool adopts the high-precision rotary table, and the transmission applies the most precise motion control mode at present-the globoidal indexing principle.

Five-axis machining center

Improve the processing efficiencyand quality of products A complete machine architecturewith sustained stabllity EfficientHeavy duty MillingOperations Improve the processing efficiencyand quality of products High response speed High rigidity and stability bed body Originatingfrom high-performancespindle and turntable technologyinEurope Applicable to a wide range of materialprocessingrequirements Innovative screw drive technology(nutrotation drives screw movement}

Main products

Five-axis machining center machine, dual-purpose machining center machine, drilling and tapping machine, parts machining center, mold machining center, engraving and milling machine, CNC lathe, gantry machining center, gantry section machine, horizontal machining center machine and other series of precision machining equipment.
