Hangzhou Huafang CNC Machine Tool Co., Ltd.

Company Introduce

Hangzhou Huafang is a high-tech enterprise in Hangzhou, a senior member enterprise of China Mechanical Engineering Society, a member enterprise of China Special Processing Machine Tool Standard Committee, and a director enterprise of China Machine Tool Industry Tool Association. It has been engaged in the research and development and manufacture of WEDM and CNC lathes for more than 30 years. The company has passed ISO9001: 2008 certification, and is one of the first batch of enterprises in China to win the title of model product of electric processing machine tools. The company is located in Shilongshan Industrial Zone, Zhuantang, Xihu District, Hangzhou. The factory building and scientific research office building cover an area of 17000 square meters, with a construction area of 18000 square meters. The company has more than 200 employees and complete processing and testing equipment. Including Taiwan Polyhedron Machining Center, UK Renishaw Laser Interferometer, Universal Tool Display, Germany Marr Roughness Tester, Digital Storage Oscilloscope, etc., and a high-quality R & D, production and marketing team, sincerely and timely provide users with high-quality products and services

HF500CB

I. Technical parameters 1 Working table size 950 × 660mm 2 Worktable stroke (X, Y) 500 × 400mm 3 Maximum machining thickness 350 mm 4 Machining taper ± 12 ° (80mm) 5 U, V working stroke ± 30mm 6 Octagonal cutting accuracy (straight) ≤ ± 0.005 mm 7 Optimum roughness (straight body) Ra ≤ 0.8 μm 8 Long-time cutting maximum efficiency ≥ 10000 mm2/H 9 Maximum molybdenum wire diameter 0.12 mm-0.25 mm 10 Wire speed variable frequency adjustable 11 Maximum load capacity 800 kg 12 Overall dimension 1870 × 1480 × 2030 mm 13 Total weight of complete machine (Kg) 2500 14 Actual power consumption ≤ 1.0 kw 1. Two-stage two-way automatic tension system (patent); 2. The electric control cabinet is equipped with "heat pump" heat dissipation patent technology (patent): Adaptive cooling, no cooling fan. In the workshop environment, suspended matters can be obviously reduced to enter the electric cabinet, and the electric cabinet can be kept clean for a long time, so that the failure rate of long-term use is greatly reduced, and meanwhile, the energy is saved and the noise is low; 3. The machine tool adopts a new structure. Through Ansys finite element analysis, the whole machine has strong rigidity and small Abbe error; 4. T-shaped bed, frame structure, 250 gray cast iron, secondary artificial aging treatment; 5. Taper (UV axis) adopts slow filament structure; 6. Set screw compensation for X, Y, U and V axes, and adopt 3-line pitch compensation for X and Y axes; 7. Five-axis servo motor direct drive, five-axis linear guide (Taiwan), five-axis ball screw, XY-axis Panasonic servo motor, Z-axis servo motor with brake function; 8, autocut (10.1) integrated programming and control, five-axis screw compensation, reverse compensation, Z-axis memory lifting; 9. Set the torque motor to set the tension value of the molybdenum wire, and automatically release the tension during shutdown to reduce the elastic fatigue of the molybdenum wire; 10. Wire feeding can be performed automatically according to the set tension value; 11. The upper and lower power inlet blocks are designed with bilateral V-shaped groove structure, which is easy to hang wires. You only need to loosen the front nut to change the side; 12. Multiple safety protection: X, Y, U, V and Z axes are equipped with digital soft limit, electronic limit and mechanical limit. It is also equipped with tension in place, thread cylinder stroke and other protections; 13. Configure various basic protection functions: automatic shutdown protection for broken wire of the machine tool, automatic rollback protection for short circuit, memory protection for power failure, automatic alarm for short circuit, automatic alarm for broken wire, and automatic stop of the wire barrel after processing; 14. Industrial computer, Dell (new) monitor, portable control box; 15. 150L double-pump slow filter element water tank; 16. Centralized lubrication of electric oil pump; 17. With drilling die; 18. Full protective cover, LED panoramic lighting.

HF450CB

I. Technical parameters 1 Working table size 950 × 640mm 2 Table stroke (X, Y) 450 × 320mm 3 Maximum machining thickness 350 mm 4 Machining taper ± 12 ° (80mm) 5 U, V working stroke ± 30mm 6 Octagonal cutting accuracy (straight) ≤ ± 0.005 mm 7 Optimum roughness (straight body) Ra ≤ 0.8 μm 8 Long-time cutting maximum efficiency ≥ 10000 mm2/H 9 Maximum molybdenum wire diameter 0.12 mm-0.25 mm 10 Wire speed variable frequency adjustable 11 Maximum load weight 600 kg 12 Overall dimension 1760 × 1410 × 2030 mm 13 Total weight of complete machine (Kg) 2500 14 Actual power consumption ≤ 1.0 kw 1. Two-stage two-way automatic tension system (patent); 2. The electric control cabinet is equipped with "heat pump" heat dissipation patent technology (patent): Adaptive cooling, no cooling fan. In the workshop environment, suspended matters can be obviously reduced to enter the electric cabinet, and the electric cabinet can be kept clean for a long time, so that the failure rate of long-term use is greatly reduced, and meanwhile, the energy is saved and the noise is low; 3. The machine tool adopts a new structure. Through Ansys finite element analysis, the whole machine has strong rigidity and small Abbe error; 4. T-shaped bed, frame structure, 250 gray cast iron, secondary artificial aging treatment; 5. Taper (UV axis) adopts slow filament structure; 6. Set screw compensation for X, Y, U and V axes, and adopt 3-line pitch compensation for X and Y axes; 7. Five-axis servo motor direct drive, five-axis linear guide (Taiwan), five-axis ball screw, XY-axis Panasonic servo motor, Z-axis servo motor with brake function; 8, autocut (10.1) integrated programming and control, five-axis screw compensation, reverse compensation, Z-axis memory lifting; 9. Set the torque motor to set the tension value of the molybdenum wire, and automatically release the tension during shutdown to reduce the elastic fatigue of the molybdenum wire; 10. Wire feeding can be performed automatically according to the set tension value; 11. The upper and lower power inlet blocks are designed with bilateral V-shaped groove structure, which is easy to hang wires. You only need to loosen the front nut to change the side; 12. Multiple safety protection: X, Y, U, V and Z axes are equipped with digital soft limit, electronic limit and mechanical limit. It is also equipped with tension in place, thread cylinder stroke and other protections; 13. Configure various basic protection functions: automatic shutdown protection for broken wire of the machine tool, automatic rollback protection for short circuit, memory protection for power failure, automatic alarm for short circuit, automatic alarm for broken wire, and automatic stop of the wire barrel after processing; 14. Industrial computer, Dell (new) monitor, portable control box; 15. 150L double-pump slow filter element water tank; 16. Centralized lubrication of electric oil pump; 17. With drilling die; 18. Full protective cover, LED panoramic lighting.

HF320PE20

Workbench size: 690 × 458mm Table stroke (XYZ): 350x450x 350mm Octagonal cutting accuracy: ≤ 0.01mm (straight body, 40 high) Maximum processing efficiency: ≤ 12000mm ²/H Taper: ± 6 ° (when the center distance between the upper and lower guide wheels is 200 mm) Maximum machining current: 8 A Best finish: Ra ≤ 1.0 um Wire diameter range: 0.10 ~ 0.25 mm Wire speed: variable frequency adjustable (up to 11 m/s) Working fluid tank capacity: 100L Voltage and power: 380v/0.8kw Repeated positioning accuracy: ≤ 0.01mm Maximum load: 600 kg Net weight of the machine: 1400 kg Machine size: 1400 × 1340 × 1700 mm Control unit: X8 (CAD) intelligent control system Executive standard: GB/T7926-2015 II. Product technology and configuration: 1. The machine bed and worktable are made of 250 gray cast iron and subject to secondary artificial aging treatment to ensure the accuracy stability; 2. Precision rolling alloy steel quenching guide rail is adopted, and cylindrical rolling parts are selected. Compared with spherical rolling parts, cylindrical rolling parts have strong bearing capacity and long service life; 3. The worktable is designed with large-span guide rail spacing, which can improve the bearing capacity and stability of the machine tool to ensure the processing accuracy; 4. The XY axis of the coordinate worktable is driven by motor direct servo control to avoid reverse clearance and noise of gear transmission; 5. The lifting column of the wire rack is a precision grade integral guide rail. Electric lifting, press the key to lift, and the verticality can be maintained after lifting or lowering. It is not necessary to unlock and adjust the verticality again after lifting or lowering; 6. The motion guide rail of the wire storage cylinder adopts the plastic pasting process, which is wear-resistant, shock-absorbing, stable in operation and lower in noise; 7. Mechanical slide rail constant tension mechanism; 8, autocut multiple cutting control system; 9. Configure various basic protection functions: automatic shutdown protection for broken wire of machine tool, automatic rollback protection for short circuit, memory protection for power failure, automatic alarm for short circuit and automatic alarm for broken wire; 10. Configure the automatic edge stop function of the wire storage cylinder after processing, which is convenient for wire removal; 11. The electric control cabinet is equipped with a patented "heat pump" heat dissipation technology (Patent No.201220694371.0), which can automatically dissipate heat without a fan, so as to ensure that the electric cabinet can work stably for a long time in a harsh environment, and at the same time, it is energy-saving, clean and noiseless; 12. Configure grating digital display; 13, with portable operation box, can control XY and UV axis, open wire, high frequency, working fluid pump, etc.; 14. Fully protective sheet metal cover.

HF320YE All-in-One

I. Technical parameters Technical specifications and parameters No. Technical parameters of project 1 Worktop size 690 × 458 mm 2 Table stroke (X, Y) 350 × 450mm (servo control drive) 3 Maximum processing thickness 350 mm adjustable 4 Machining taper 6 ° (when the center distance between the upper and lower guide wheels is 200mm) 5 U, V working stroke ± 20mm 6 Octagonal cutting accuracy (straight) ≤ ± 0.005 mm 7 Long-time cutting maximum efficiency ≥ 180 mm2/min 8 When the speed of molybdenum wire loss is 100 mm2/min, the continuous cutting is 400,000 mm2, and the wire loss is ≤ 0.01 mm. 9 Maximum diameter of molybdenum wire ≤ 0.25mm 10 Wire speed variable frequency adjustable 11 Patented heat dissipation technology of automatic heat dissipation "heat pump" (Patent No.201220694371.0) 12Maximum load weight 600 kg 13 Overall dimension of main machine 1860 × 1770 × 1750mm 14 Actual power consumption ≤ 0.8kw II. Product technology and configuration: 1. The machine bed and worktable are made of 250 gray cast iron and subject to secondary artificial aging treatment to ensure the accuracy stability; 2. Precision rolling alloy steel quenching guide rail is adopted, and cylindrical rolling parts are selected. Compared with spherical rolling parts, cylindrical rolling parts have strong bearing capacity and long service life; 3. The worktable is designed with large-span guide rail spacing, which can improve the bearing capacity and stability of the machine tool to ensure the processing accuracy; 4. The XY axis of the coordinate worktable is driven by motor direct servo control to avoid reverse clearance and noise of gear transmission; 5. The lifting column of the wire rack is a precision grade integral guide rail. Electric lifting, press the key to lift, and the verticality can be maintained after lifting or lowering. It is not necessary to unlock and adjust the verticality again after lifting or lowering; 6. The motion guide rail of the wire storage cylinder adopts the plastic pasting process, which is wear-resistant, shock-absorbing, stable in operation and lower in noise; 7. Mechanical slide rail constant tension mechanism; 8, autocut multiple cutting control system; 9. Configure various basic protection functions: automatic shutdown protection for broken wire of machine tool, automatic rollback protection for short circuit, memory protection for power failure, automatic alarm for short circuit and automatic alarm for broken wire; 10. Configure the automatic edge stop function of the wire storage cylinder after processing, which is convenient for wire removal; 11. The electric control cabinet is equipped with a patented "heat pump" heat dissipation technology (Patent No.201220694371.0), which can automatically dissipate heat without a fan, so as to ensure that the electric cabinet can work stably for a long time in a harsh environment, and at the same time, it is energy-saving, clean and noiseless; 12. Configure grating digital display; 13, with portable operation box, can control XY and UV axis, open wire, high frequency, working fluid pump, etc.; 14. Fully protective sheet metal cover.
